Restore intrathoracic pressure and lung expansion with safe, controlled pleural drainage.
Choose dry suction regulation or water seal control, each designed to remove accumulated fluid, blood, or air from the pleural space between the lungs and the chest wall.
Vertical Integration:
End-to-end control of design, manufacturing and distribution of our healthcare devices and supplies
Supply Chain Reliability:
A robust network with 4 distribution centres ensures reliable operation and inventory security.
Regulatory Expertise:
We follow North American compliance
and clinical standards.
Frequently Asked Questions
Review answers to common questions regarding our product lines, distribution network, and regulatory compliance.
-
Is sterile water included?
Yes, each chest drain includes 30mL of sterile water.
-
What is the operating pressure range?
-10 cmH2O to -40 cmH2O
-
Does the product include an easy-access sampling port?
Yes, on the chest drain unit with a sampling window and a needle-less luer lock connection.
-
Can it be used as a gravity drain?
Yes, it can be used as a gravity drain with suction off/disconnected.
-
What are the benefits of a dry drain?
Dry/dry drains are easier to setup, less affected by tilting and water evaporation, and more quiet than wet drains.
-
Does the chest drain need to be replaced if tipped over?
Yes, the chest drain should be replaced with a new one if it is tipped over while draining.
Product Technical Specifications
Contact UsMaterials
MED-RX chest drains do not contain DEHP, PVC or Latex, however they do contain BPA.
Care & handling instructions and storage conditions
Do not obstruct the suction control vent plug or positive pressure relief valve located on top of drain.
Do not manually depress high negative pressure vent when patient is on gravity drainage or when suction is not operating. Do not separate CPC in-line connector prior to clamping off patient tube first.
Do not keep patient tube clamped during drainage collection or patient transport.
For single patient use only. Do not reuse, reprocess or resterilize.
Reuse, reprocessing or re-sterilization may compromise the structural integrity of the device and/or lead to device failure which, in turn, may result in patient injury, illness or death.
Do not use if there is any sign of damaged package or product malfunction. If there is any breakage or cracking to the package/product, do not use the product and replace it with a new one.
This device can only be used by physicians and clinical staff.
Discard the product per hospital’s procedure.
Download Resources
Ordering Information
Request a Quote| H02100 | PLEURAL DRAIN DRY SEAL SYSTEM | 5 EA/CA |
| H02004 | PLEURAL DRAIN WET SEAL SYSTEM | 5 EA/CA |
